HP 200 - Removing the Bail

         
   
 Open the window.  Move the cartridgeĆcarriage to the
extreme left.
Cartridge carriage

 Push both of the plastic ends of the bail towards each other to release them from the holes in
the sideplates, and lift the bail up and clear of the plotter.
1
1
2
Push
Push
      
         
 
6Ć56 Removal and Replacement
C3187Ć90000
  
