6Ć3 Removal and ReplacementC3187Ć90000

Required Tools

The following are the tools required to disassemble and repair the plotters.

D Long Torx screwdriver with the indicated attachments:

T9 T10

T20

T15 T25

D 90

TorxĆ15 key:

D Pozidriv PZ1 screwdriver:

D Small flatĆblade screwdriver:
