Align
Cartridges
7Ć2 Calibrations
C3187Ć90000
When to Calibrate the Plotter
Indications or Repairs Performed Calibration Required
Jagged lines on plots Cartridge Alignment
Cartridges are reseated or replaced Cartridge Alignment
Drive roller is removed or replaced Accuracy Calibration
Media (X-axis) motor is replaced Accuracy Calibration
Configuration-plot X-mark distance is not
500mm (1mm)
Accuracy Calibration
Carriage or carriage LED is removed or replaced Cartridge Alignment
and Setup-Sheet Calibration
Edge-detect failures occur Cartridge Alignment
Bail failures occur during media loading Bail Calibration
Bail sensor is removed or replaced Bail Calibration
Bail-lift mechanism is removed or replaced Bail Calibration
Media sensor is removed or replaced Media-Sensor Calibration
Leading and trailing margins of a plot are greater
than 17 mm (0.67 in)
Media-Sensor Calibration
Problems occur scanning a setup sheet. Setup-Sheet Calibration
EEROM is cleared or main PCA is replaced (In this order:)
1. Bail Calibration
2. Media-Sensor Calibration
3. Cartridge Alignment
4. Accuracy Calibration
5. Setup-Sheet Calibration
Service Mode
  
 Switch the plotter off.
 While holding the
Align Cartridges key down,
switch the plotter on.
 Once the
Busy LED lights up, release the Align Cartridges key.
     !      
      
     
Draft, Final, Paper  Transl/Vellum   
          
