HP 200 - Removing the Window Sensor

 Remove the electronicsĆenclosure
cover  page 6Ć5.
 Remove the window  page 6Ć15.
 Remove the center cover  page 6Ć16.
 Remove the right endcover  page 6Ć19.
 Disconnect the windowĆsensor cable
connector from the main PCA.
Window-sensor
connector
Clip
Clip
    
    
      
 
Ferrite
 Carefully feed the windowĆsensor cable out from the electronics enclosure and from under
the motor assemblies, unclipping it from the holding clips and ferrite.
      
6Ć24 Removal and Replacement
C3187Ć90000
   
