HP 200 User Manual

ALT
Bail Cycle Test
ALT
Bail Sensor Test
SHIFT
Electrical Test
8Ć22 Removal and Replacement
C3187Ć90000
Performing the Service Tests
The following paragraphs describe how to perform the various service tests. You know that a
test has failed if a system error is indicated by means of the frontĆpanel LEDs.
Bail Cycle Test
, Enter service mode (see page 7Ć2).
. Hold down the
ALT key and press Bail Cycle Test.

Busy              
A Press the
ALT (Cancel) key when you want to stop the test.
BailĆSensor Test
, Enter service mode (see page 7Ć2).
. Hold down the
ALT key and press Bail Sensor Test.

Busy   
A Open the window within 120 seconds.
 
Busy       
4 Manually raise the bail.

Ready  
5 Press the
ALT (Cancel) key when you want to stop the test, and lower the window.
Electrical Test
, Enter service mode (see page 7Ć2).
. Hold down the
SHIFT key and press Electrical Test.

Busy               

