 Disconnect the ac connector and the dc powerĆdistribution connector from the powerĆsupply
PCA.
 Remove the electronicsĆenclosure
cover  page 6Ć5.
 Open the flexible, DANGER HIGH
VOLTAGE," insulation cover.
         
   
dc power-distribution
connector
ac connector
6Ć12 Removal and Replacement
C3187Ć90000
   
