Lift the fan clear of the plotter.
Remove the electronicsĆenclosure
cover page 6Ć5.
Fan connector
Open the flexible, DANGER HIGH
VOLTAGE," insulation cover.
Disconnect the fan connector from the
main PCA and holding clip.
Remove the two screws that secure the
fan to the electronics enclosure.
Torx-20
6Ć14 Removal and Replacement
C3187Ć90000
To Next Page
