Move the overdrive roller to the right until it has completely cleared the left sideplate but
not entered the hole in the right sideplate.
Release the overdrive roller from the overdrive bushing (small black clips underneath the
media separator), and lift the overdrive roller clear of the plotter.
6Ć61 Removal and ReplacementC3187Ć90000
