10Ć4 Parts and Diagrams
C3187Ć90000
Parts List: Legs and Media Bin
Reference
on
Drawing
HP Part Number Check
Digit
Quantity
Description
1 C2847-60002 6 2 Leg Assembly (D/A1 Size)
C2848-60002 7 2 (E/A0 Size)
2 C3185-00034 9 1 Stand Brace (D/A1 Size)
C3186-00034 0 1 (E/A0 Size)
3 C2847-60061 7 1 Hardware Kit
4 1492-0145 8 4 Caster Assembly
5 C2847-00006 4 1 Media Bin Front (D/A1 Size)
C1633-00020 2 1 (E/A0 Size)
6 C2847-00012 2 1 Media Bin Adjust (D/A1 Size)
C1633-00044 0 1 (E/A0 Size)
7 C2847-00005 3 1 Media Bin Back (D/A1 Size)
C1633-00019 9 1 (E/A0 Size)
8 no part number 4 M3 Thread-Forming Screw
    
Part Number C3185A = Complete legs and media bin for D/A1Ćsize plotters.
Part Number C3186A = Complete legs and media bin for E/A0Ćsize plotters.
