Printer overview
●
Front view 1
●
Front view 2
●
Rear view
Front view 1
Figure 1-1 Front view 1
Table 1-1 Front view 1
Callout Description Callout Description
1 Document feeder cover 8 Power receptacle
2 Document feeder width guides 9 Handles
3 Document input tray 10 Standard tray (Tray 3)
4 Control panel 11 Standard tray (Tray 2)
5 Side door 12 Front door
6 Tray 1 (MP) 13 Front door handle
7 Power-switch 14 Paper output tray
4 Chapter 1 Introduction ENWW
