Loading paper in the tray
●
Tray overview
●
Standard tray / optional dual cassette feeder
●
Tray 1 (MP)
●
Media sizes automatically detected
Tray overview
To change the size, you need to adjust the paper guides.
1 Locking switch
2 Paper capacity indicator
3 Paper length guide
4 Paper width guide
IMPORTANT: If you do not adjust the guide, it may cause paper registration, image skew, or jamming of the
paper.
Standard tray / optional dual cassette feeder
Load the print media you use for the majority of your print jobs into the standard tray. The standard tray can
hold a maximum of 1,040 sheets of plain paper.
You can purchase an optional dual cassette feeder and attach it below the standard tray to load an additional
1,040 sheets of plain paper.
42 Chapter 3 Media and tray ENWW
