HP M525

2. Release two tabs, and then rotate the roller out and away from the product to remove it.
TIP: It might be easier to release the tabs by using a small flat blade screwdriver.
Figure 1-144 Remove the Tray 1 pickup roller (2 of 2)
96 Chapter 1 Removal and replacement ENWW
