Reinstall the right handle cover and bracket
1. Carefully raise the right side of the product, find the three slots in the chassis (callout 1), and the
three tabs (callout 2) along the bottom of the cover.
Figure 1-104 Reinstall the right handle cover and bracket (1 of 2)
2
1
2. Rotate the cover up to engage the tabs with the slots, and then slide the cover toward the front of
the product to install it.
Figure 1-105 Remove the right handle cover and bracket (2 of 2)
ENWW
Removal and replacement procedures
69
