Left cover
1. Before proceeding, remove the following:
Rear cover assembly. See
Rear cover assembly on page 44.
2. Remove one screw (callout 1).
Figure 1-71 Remove the left cover (1 of 4)
1
48 Chapter 1 Removal and replacement ENWW
