7. Rotate the bottom of the rear cover assembly away from the product.
Figure 1-69 Remove the rear cover assembly (7 of 8)
8. Pull down on the rear cover assembly to remove it.
Figure 1-70 Remove the rear cover assembly (8 of 8)
Reinstallation tip Insert the top of the cover first to make sure the tabs are in place and then rotate
the bottom of the cover into place.
ENWW
Removal and replacement procedures
47
