Sub fan and fan duct
1. Before proceeding, remove the following:
●
Formatter cover. See
Formatter cover on page 37.
●
Formatter PCA. See
Formatter PCA on page 38.
●
Stapler cover or substitute stapler cover. See
Stapler cover on page 40 or Substitute stapler
cover on page 42.
●
Stapler assembly. See
Stapler assembly on page 43.
●
Rear cover assembly. See
Rear cover assembly on page 44.
●
Left cover. See
Left cover on page 48.
●
Right-rear cover. See
Right-rear cover on page 50.
●
Tray 1 cover. See
Tray 1 cover on page 52.
●
Cartridge-door assembly. See
Cartridge-door assembly on page 54.
●
Rear scanner cover. See
Rear scanner cover on page 56.
●
Right cover assembly. See
Right cover assembly on page 61.
●
Right handle cover and bracket. See
Right handle cover and bracket on page 66.
●
Image scanner whole unit kit. See
Image scanner whole unit kit on page 91.
●
Top cover. See
Top cover on page 120.
●
DC controller. See
DC controller on page 127.
●
Low-voltage power supply. See
Low-voltage power supply (LVPS) on page 131.
