Stapler assembly
1. Before proceeding, remove the following:
Formatter cover. See
Formatter cover on page 37.
Stapler cover or substitute stapler cover. See
Stapler cover on page 40 or Substitute stapler
cover on page 42.
2. Disconnect one connector (callout 1), remove two screws (callout 2), and then remove the stapler
assembly.
Figure 1-62 Remove the stapler assembly
1
2
ENWW
Removal and replacement procedures
43
