HP M525

5. Open the lower-rear door, and then release one tab (callout 1).
Figure 1-67 Remove the rear cover assembly (5 of 8)
1
6. Release one tab (callout 1).
Figure 1-68 Remove the rear cover assembly (6 of 8)
1
46 Chapter 1 Removal and replacement ENWW
