3. Disconnect three connectors (callout 1), and release one wire harness from the retainer (callout 2).
Figure 1-159 Remove the fuser (2 of 4)
1
2
4. Remove four screws (callout 1).
Figure 1-160 Removing the fuser (3 of 4)
1
106 Chapter 1 Removal and replacement ENWW
