HP M525

Item Description Item Description Item Description
J2104 Subfan (FM2)
Rear door sensor
(PS8001)
Scanner motor
(M3)
J2306 Interlock switch
(SW260)
J2701 LVPS
J2105 Power switch
(SW240)
J2307 Tray detection
switch (SW235)
J2702 LVPS
J2200 HVPS J2308 Main fan (FM1) J2703 Cartridge door
switch (SW501)
J2201 Paper feeder
connector
J2310 CST pickup
solenoid (SL2)
J2704 Cartridge door
switch (SW501)
J2301 CST media out
sensor (PS3)
J2311 MPT pickup
solenoid (SL1)
8 Chapter 1 Removal and replacement ENWW
