HP M525

Table 2-14 Internal assemblies (3 of 6)
Ref Description Part number Qty
1 Registration roller assembly RM1-8507-000CN 1
2 Roller, multipurpose RL1-2412-000CN 1
3 Transfer lower guide assembly RM1-6315-000CN 1
4 Cassette, Tray 2 RM1-8512-000CN 1
5 Base plate roller assembly RM1-6306-000CN 4
6 Roller, transfer RM1-6321-000CN 1
7 Pad, multipurpose separation RC2-8575-000CN 1
8 Separation holder assembly RM1-6303-000CN 1
ENWW
Internal assemblies (3 of 6)
191
