HP M525

Table 2-16 Internal assemblies (5 of 6)
Ref Description Part number Qty
1 Fan, main RK2-2416-000CN 1
2 Tray 2, paper pickup assembly RM1-8505-000CN 1
3 Idler roller assembly RM1-8506-000CN 1
4 Multipurpose sensor PCA RM1-8621-000CN 1
5 Fuser assembly (universal) RM1-8508-000CN 1
6 Low voltage power supply assembly RM1-8514-000CN 1
7 DC controller PCA RM1-8615-000CN 1
8 Interlock switch assembly RM1-8499-000CN 1
9 Tray pickup roller assembly RM1-6323-000CN 1
Not shown Stapler assembly (no cable) (see
Stapler assembly on page 43) 5851-0786 1
Not shown Stapler cable (see
Stapler assembly on page 43) CF116-60106 1
Not shown Fax cradle, black plastic 5851-0672 1
Not shown Hard drive, bracket 5851-3453 1
Not shown Fax, cable 5851-3499 1
Not shown Fax, cable, Israel 8120-8913 1
Not shown Fax, cable, rest of the world 8120-0811 1
Not shown Fax, cable, Switzerland 8120-0844 1
Not shown Formatter, standard CF104-69001 1
Not shown Formatter, standard (China only) CF116-67914 1
ENWW
Internal assemblies (5 of 6)
195
