10 HP ProLiant ML370 Generation 4 Server Reference and Troubleshooting Guide
Item Description
1 UID switch and LED
2 Internal system health LED
3 Front panel USB port
4 External system health LED
5 NIC link/activity LED
6 Power on/Standby button/LED assembly
7 Diskette drive*
8 Removable media bays
9 Hot-plug SCSI hard drive bays (SCSI IDs 0 through 5)
10 Optional SAS-SATA hard drive bays (1 through 8)
* Open the media door on the rack server to access the diskette drive.
