106 HP ProLiant ML370 Generation 4 Server Reference and Troubleshooting Guide
Cable connector identification
Item Cable Description
1 IDE connector
2 Diskette drive connector ("Diskette drive cabling" on
page 108
)
3 Fan cable connector
4 SCSI port 2 ("Installing a half-height or full-height media
device" on page 70
)
5 SCSI port 1 ("Installing a half-height or full-height media
device" on page 70)
6 Power supply connector
7 Power supply signal connector

HP ProLiant ML370 Generation 4 Specifications

General

Processor	Intel Xeon
Processor Socket	Socket 604
Chipset	Intel E7520
Memory Slots	8 DIMM slots
RAID Support	RAID 0, 1, 5
Form Factor	Tower
Storage	SATA
Expansion Slots	6 PCI-X slots
Power Supply	Redundant power supply optional
Operating System Support	Linux
Drive Bays	Up to 8 hot-plug drive bays
