99
Server cabling
In this section
Storage device cabling guidelines ................................................................................................99
Hot-plug SCSI cabling..................................................................................................................99
Cable connector identification....................................................................................................106
CD-ROM drive cabling ..............................................................................................................107
RILOE II cabling........................................................................................................................107
Diskette drive cabling.................................................................................................................108
External storage cabling .............................................................................................................109
Storage device cabling guidelines
CAUTION: To prevent damage to the equipment, be sure that
the server is powered down, all cables are disconnected from the back
of the server, and the power cord is disconnected from the grounded
(earthed) AC outlet before installing devices.
CAUTION: To prevent damage to electrical components,
properly ground the server before beginning any installation procedure.
Improper grounding can cause electrostatic discharge.
Hot-plug SCSI cabling
Integrated Simplex SCSI Cabling (on page 100)
Integrated Duplex SCSI Cabling (on page 101
)
Array Controller Simplex SCSI Cabling (on page 102
)
Array Controller Duplex SCSI Cabling (on page 102
)
Integrated SCSI Cabling with Optional Internal Two-Bay Hot-Plug SCSI Drive
Cage (on page 104
)
