Server component identification 15
Item Description Item Description
1 Redundant fan 2 connector 13 Power supply connector
2 System maintenance switch 14 SCSI port 1
3 System battery 15 PPM socket 2
4 Redundant fan 4 connector 16 PPM socket 1 (populated)
5 64-bit/100-MHz PCI-X slot,
bus 3
17 SCSI port 2
6 64-bit/100-MHz PCI-X slot,
bus 3
18 Fan cable connector
7 64-bit/100-MHz PCI-X slot,
bus 7
19 Diskette drive connector
8 64-bit/100-MHz PCI-X slot,
bus 7
20 IDE connector
9 PCI Express x4 slot, bus
11 *
21 DIMM slots
10 PCI Express x4 slot, bus
14 *
22 Processor 1
11 RILOE II connector (install
adapter into slot 1) **
23 Processor 2
12 Power supply signal
connector
* x8 PCI Express cards are supported, but will run at x4 speeds.
** The server comes with iLO remote management capability embedded on the system
board. The 30-pin remote management connector for the RILOE II board is provided if the
server environment requires an upgrade for improved Remote Console performance.
System maintenance switch
The system maintenance switch (SW1) is a six-position switch that is used for
system configuration. The default position for all six positions is Off.
