Server cabling 103
In the array controller duplex SCSI cabling configuration, the optional PCI array
controller controls up to four hard drives on one SCSI bus and two hard drives on
the other SCSI bus.
Item Component description SCSI IDs managed
1 SCSI cable 0, 1, 2, 3
2 SCSI cable * 4, 5
* One SCSI cable is provided with the server.
