HP ProLiant ML370 Generation 4 User Manual

Hardware options installation 77
1. Power down the server ("Powering down the server" on page 27).
2. Extend or remove the server from the rack ("Extending the server from the
rack" on page 28
).
3. Remove the front bezel door, if necessary.
4. Remove the access panel ("Removing the access panel" on page 30
).
5. Remove the redundant fan cage retaining bracket from the chassis.
IMPORTANT: Do not discard the fan cage retaining bracket. The
bracket is required for proper fan operation.
6. Slide the redundant fan cage into the slots on the chassis wall.

HP ProLiant ML370 Generation 4 Specifications

General

Processor	Intel Xeon
Processor Socket	Socket 604
Chipset	Intel E7520
Memory Slots	8 DIMM slots
RAID Support	RAID 0, 1, 5
Form Factor	Tower
Storage	SATA
Expansion Slots	6 PCI-X slots
Power Supply	Redundant power supply optional
Operating System Support	Linux
Drive Bays	Up to 8 hot-plug drive bays
