Figure 6-9 Front Panel Board Cable Location on Backplane
Front Panel Board
Connector
System Backplane
Removing and Replacing a Front Smart Fan Assembly
The Front Smart Fan Assembly is located in the front of the chassis. The fan assembly is a hot
swappable component.
150 Removing and Replacing Components
