2 Server Site Preparation
This chapter describes the basic server configuration and its physical specifications and
requirements.
Dimensions and Weights
This section provides dimensions and weights of the system components. Table 2-1 gives the
dimensions and weights for a fully configured server.
Table 2-1 Server Dimensions and Weights
PackagedStandalone
35.75 (90.8)17.3 (43.9)Height- Inches (centimeters)
28.0 (71.1)17.5 (44.4)Width- Inches (centimeters)
28.38 (72.0)30.0 (76.2)Depth- Inches (centimeters)
665.0
2
(302.0)220.0
1
(100.0)Weight - Pounds (kilograms)
1 This weight represents a fully configured server before it is installed in a rack.
2 The packaged weight represents a server installed in a 2-m rack. The packaged weight includes a fully configured
server in a 2-m rack with a rear door, rail slide kit, line cord anchor kit, interlock assembly, cable management arm,
120-lb ballast kit, and a 60-A PDU. The shipping box, pallet, and container, not included in the packaged weight in
Table 2-1, adds approximately 150.0-lb to the total system weight when shipped. The size and number of miscellaneous
pallets will be determined by the equipment ordered by the customer.
Table 2-2 provides component weights for calculating the weight of a server not fully configured.
Table 2-3 provides an example of how to calculate the weight. Table 2-4 is a blank worksheet for
calculating the weight of the server. To determine the overall weight, follow the example in
Table 2-3, and complete the worksheet in Table 2-4 for your system.
Table 2-2 Server Component Weights
Weight lb (kg)DescriptionQuantity
90.0 (41.0)Chassis1
27.80 (12.61) eachCell board1 - 2
12 (5.44) (estimate)System backplane1
20.4 (9.25)PCI-X card cage assemply1
18.0 (8.2) eachBulk power supply2
1.0 (0.45)Mass storage backplane1
5.0 (2.27) eachPCI-X power supplies2
1.60 (0.73) eachHard disk drive1 - 4
2.20 (1.00) eachRemovable media disk drive1
Table 2-3 Example Weight Summary
Weight (kg)MultiplyQuantityComponent
107.20 (48.64)27.8 (12.16)2Cell board
1.36 (0.61)0.34 (0.153)4PCI card (varies - used
sample value)
36.0 (16.4)18 (8.2)2Power supply (BPS)
Dimensions and Weights 35
