CAUTION: Observe all ESD safety precautions before attempting this procedure. Failure to
follow ESD safety precautions could result in damage to the server.
Figure 6-16 DVD/DAT Location
Removing a DVD/DAT Drive
1. To remove the DVD/DAT, depress the front locking latch to loosen the drive from the chassis.
2. Partially slide the drive out.
3. Disengage the cables from the rear of the DVD/DAT.
4. Remove the rails and clips from the drive.
5. Completely slide the drive from the chassis. (Figure 6-17).
Removing and Replacing a Half-Height DVD/DAT Drive 157
