Figure 3-13 Foam Block Removal
8. Locate and identify the caster assemblies. Use the following table to identify the casters.
NOTE: The caster part number is stamped on the caster mounting plate.
Table 3-2 Caster Part Numbers
Part NumberCaster
A6753-04001Right front
A6753-04005Right rear
A6753-04006Left front
A6753-04007Left rear
9. Locate and remove one of the four screws from the plastic pouch. Attach the a caster to the
server.
Wheel Kit Installation 55
