HPE FlexFabric 5940 SERIES Command Reference

6
[Sysname-acl-ipv4-basic-2000] description This is an IPv4 basic ACL.
Related commands
display acl
display acl
Use display acl to display ACL configuration and match statistics.
Syntax
display acl [ ipv6 | mac ] { acl-number | all | name acl-name }
Views
Any view
Predefined user roles
network-admin
network-operator
Parameters
ipv6: Specifies the IPv6 ACL type.
mac: Specifies the Layer 2 ACL type.
acl-number: Specifies an ACL by its number.
• 2000 to 2999 for basic ACLs.
• 3000 to 3999 for advanced ACLs.
• 4000 to 4999 for Layer 2 ACLs.
all: Specifies all ACLs of the specified type.
name acl-name: Specifies an ACL by its name. The acl-name argument is a case-insensitive string
of 1 to 63 characters.
Usage guidelines
This command displays ACL rules in config or auto order, whichever is configured.
To specify the IPv4 ACL type, do not specify the ipv6 or mac keyword.
Examples
# Display configuration and match statistics for IPv4 basic ACL 2001.
<Sysname> display acl 2001
Basic IPv4 ACL 2001, 1 rules, match-order is auto,
This is an IPv4 basic ACL.
ACL's step is 5
rule 5 permit source 1.1.1.1 0
rule 5 comment This rule is used on Ten-GigabitEthernet1/0/1.
Table 1 Command output
Field Description
Basic IPv4 ACL 2001
Type and number of the ACL. The following field information is about IPv4
basic ACL 2000.
1 rules The ACL contains two rules.
match-order is auto
The match order for the ACL is
auto
, which sorts ACL rules in depth-first
order. This field is not displayed when the match order is
config
.
