HPE FlexFabric 5940 SERIES Command Reference

36
Table 15 Command output
Field Description
Classifier Traffic class name and its match criteria.
Operator
Match operator you set for the traffic class. If the operator is AND, the traffic class
matches the packets that match all its match criteria. If the operator is OR, the traffic
class matches the packets that match any of its match criteria.
Rule(s) Match criteria.
if-match
Use if-match to define a match criterion.
Use undo if-match to delete a match criterion.
Syntax
if-match match-criteria
undo if-match match-criteria
Default
No match criterion is configured.
Views
Traffic class view
Predefined user roles
network-admin
Parameters
match-criteria: Specifies a match criterion. Table 16 shows the available match criteria.
Table 16 Available match criteria
Option Description
acl
[
ipv6
] { acl-number |
name
acl-name }
Matches an ACL.
The value range for the acl-number argument is as follows:
• 2000 to 3999 for IPv4 ACLs.
• 2000 to 3999 for IPv6 ACLs.
• 4000 to 4999 for Layer 2 MAC ACLs.
The acl-name argument is a case-insensitive string of 1 to 63 characters,
which must start with an English letter. To avoid confusion, make sure the
argument is not
all
.
any
Matches all packets.
control-plane protocol
protocol-name&<1-8>
Matches control plane protocols.
The protocol-name&<1-8> argument specifies a space-separated list of up
to eight system-defined control plane protocols. For available
system-defined control plane protocols, see Table 17.
control-plane
protocol-group
protocol-group-name
Matches a control plane protocol group.
The protocol-group-name argument can be
critical
,
important
,
management
,
monitor
,
normal
, or
redirect
.
customer-dot1p
dot1p-value&<1-8>
Matches 802.1p priority values in inner VLAN tags of double-tagged
packets.
