Table 5-35 IP address planning
Device Internal IP Address External IP Address
Camera Example: 192.168.248.50; range:
192.168.248.50–192.168.248.199
Camera external IP
address
NOTE
The 192.168.246.X
network segment
cannot be set.
VCN/
IVS1800
Example: 192.168.248.51; range:
192.168.248.50–192.168.248.199
VCN or IVS1800
external IP address
NOTE
The 192.168.246.X
network segment
cannot be set.
Procedure
Step 1 Log in to the camera web system and enable ONVIF.
1. Remove the network cables that connect the smart ETH gateway to the LAN1
and LAN2 ports on the ECC800-Pro.
2. Use a network cable to connect the PC to the PoE port on the smart ETH
gateway. Then, set the local IP address of the PC to 192.168.0.11.
3. Remove the camera shell and hold down the reset button for 6s to 10s to
restart the camera.
Figure 5-58 Reset button
(1) Reset button
4. Enter the camera IP address (192.168.0.120 by default) in the address bar of
the Internet Explorer and press Enter. The camera WebUI is displayed.
5. Set the password as prompted upon the rst login. Then use the new
password to log in.
FusionModule2000-S Smart Modular Data Center
User Manual 5 Power-On Commissioning
Issue 07 (2022-09-30) Copyright © Huawei Technologies Co., Ltd. 222
