Huawei FusionModule2000-S

System
Category
Component Document
NetEco (For Customer) iMaster NetEco Product
Documentation (Data Center)
(V600R022C10_01) (HDX)_EN
Others - FusionModule2000-S Smart Modular Data
Center Quick Guide includes the following
documents:
● FusionModule2000-S Smart Modular
Data Center Installation Quick Start
● FusionModule2000-S Smart Modular
Data Center Management System
Wiring Diagram
Cable tray Indoor Cable Tray Installation Guide
Base FusionModule2000 Smart Modular Data
Center Cabinet Base Design Diagram
NO TE
The ECC800/NetEco version may vary. Click on the ECC800/NetEco WebUI to obtain
the current version.
2.5 Installation Scenarios
Figures in this section are for reference only. The actual installation may vary.
Figure 2-3 Floor plan of the
simplied single-row containment
FusionModule2000-S Smart Modular Data Center
User Manual 2 Installation Preparations
Issue 07 (2022-09-30) Copyright © Huawei Technologies Co., Ltd. 32
