Figure 5-27 Measuring the current
----End
5.2.6 (Optional) Power-O
Step 1 Tap Shutdown on the home screen.
Step 2 Turn
o the active power switch QF1 and standby power switch QF2.
Step 3 (Optional) If the power supply needs to be disconnected for maintenance or for a
long period, turn o the upstream power input switch for the smart cooling
system.
----End
5.2.7 Checking After Commissioning
Check Item
Check Result
The thermal insulation foam of the copper pipes and
the bottom plate are free of oil stains and are clean.
□ Passed □ Failed
The needle valve plug is secured (torque of 0.45±0.05
N·m), and the valve bonnet is tightened. The needle
valve thermal insulation foam is restored.
□ Passed □ Failed
The foreign matter on the water pan and bottom plate
is cleaned up.
□ Passed □ Failed
The air lters are correctly installed according to the air
ow direction on the frame.
□ Passed □ Failed
5.3 Power-On Commissioning for the Management
System
FusionModule2000-S Smart Modular Data Center
User Manual 5 Power-On Commissioning
Issue 07 (2022-09-30) Copyright © Huawei Technologies Co., Ltd. 176
