Figure 3-91 Installing the camera mounting plate
----End
3.10.11 Installing Aisle T/H Sensors
3.10.11.1 Rules for Deploying T/H Sensors
T/H sensors can be deployed in cold and hot aisles.
Cold and Hot Aisle Containment
● In the cold and hot aisle containment scenario, install T/H sensors on the
front and rear doors of one in every six cabinets, where the cabinet is an IT
cabinet.
Components shown in the same background color belong to the same area.
FusionModule2000-S Smart Modular Data Center
User Manual 3 Hardware Installation
Issue 07 (2022-09-30) Copyright © Huawei Technologies Co., Ltd. 104
