Step 3 Remove the monitoring network cable from the camera and remove the camera.
Figure 6-16 Removing the camera
Step 4 Install the new camera and SD card. Then, set parameters and commission the
camera according to the commissioning guide.
Step 5 Check that the camera functions properly.
----End
6.3.14 Replacing an IVS1800
Prerequisites
● Recommended tool: Phillips screwdriver
● An IVS1800 needs to be replaced.
● A spare IVS1800 of the same model is available and functional.
Context
Videos cannot be recorded during the replacement of the IVS1800.
Do not operate with power on. Take appropriate insulation measures.
FusionModule2000-S Smart Modular Data Center
User Manual 6 Operation and Maintenance
Issue 07 (2022-09-30) Copyright © Huawei Technologies Co., Ltd. 313
