Figure 3-36 Installing a side sealing plate
Step 6 Secure the side sealing plates. Use four M5x10 tapping screws to secure a side
sealing plate to the aisle door mechanical part on the inner side of the glass door
near the cabinet, as shown in the following
gure.
FusionModule2000-S Smart Modular Data Center
User Manual 3 Hardware Installation
Issue 07 (2022-09-30) Copyright © Huawei Technologies Co., Ltd. 67
