9 Telnet and SSH
Quidway NetEngine20/20E
Configuration Guide - Basic Configurations
9-26 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 05 (2010-01-30)
9.8 Configuration Examples
9.8.1 Example for Configuring Telnet Terminal Services
Networking Requirements
As shown in Figure 9-5, Router A and Router B can ping through each other. Users can log in
to Router B from Router A through Telnet.
Figure 9-5 Networking diagram of the Telnet terminal services mode
GE1/0/0
1.1.1.1/24
GE1/0/0
1.1.1.2/24
RouterB
RouterA
Configuration Roadmap
The configuration roadmap is as follows:
1. Configure the authentication mode and the password of the user interface VTY0 to
VTY4 on Router B.
2. Users need to input the password when they log in to Router B from Router A through
Telnet.
Data Preparation
To complete the configuration, you need the following data:
z
The host address of Router B
z
The authentication mode and the password
Configuration Procedure
Step 1 Configure the IP address.
# Configure Router A.
<RouterA> system-view
[RouterA] interface gigabitethernet1/0/0
[RouterA-GigabitEthernet1/0/0] ip address 1.1.1.1 24
# Configure Router B.
<RouterB> system-view
[RouterB] interface gigabitethernet1/0/0
[RouterB-GigabitEthernet1/0/0] ip address 1.1.1.2 24
Step 2 Configure the authentication mode and the password of Telnet on Router B.
<RouterB> system-view
