2 Establishment of the Configuration Environment
Quidway NetEngine20/20E
Configuration Guide - Basic Configurations
2-6 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 05 (2010-01-30)
2.4 Establishing the Configuration Environment Through
the AUX Port
2.4.1 Establishing the Configuration Task
Applicable Environment
If you cannot configure the router by local login and there is no reachable route to other
routers, connect the serial port of the PC and the AUX port of the router through the Modem.
Pre-configuration Tasks
Before configuring the router through the AUX port dialup, complete the following tasks:
z
Preparing the PC/terminal (including the serial port and RS-232 cable)
z
Preparing the PC terminal emulation program (such as Windows XP hyper terminal)
z
Preparing two Modems
Data Preparation
To configure the router, you need the following data.
No. Data
1 Type of terminals
2 Terminal communication parameters
3 Modem communication parameters
Configuration Procedures
No. Procedure
1 Establishing the Physical Connection
2 Initializing and Configuring the Modem on the Interface
3 Configuring the Connection Between Remote Terminal and the Router
4 Logging In to the Router
2.4.2 Establishing the Physical Connection
Step 1 Connect the Modem with the PC and the network.
Step 2 Connect the Modem with the router through the AUX port and the network.
----End
