Quidway NetEngine20/20E
Configuration Guide - Basic Configurations 2 Establishment of the Configuration Environment
Issue 05 (2010-01-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2-3
Do not modify the IP address of the router when you configure the router through Telnet because the
modification may disconnect Telnet. If necessary, set up the connection again after entering a new IP
address.
2.1.3 Establishing the Configuration Environment Through the
AUX Port
Applicable Environment
You can configure the router by remote login.
Applications
If you cannot configure the router by local login and there is no reachable route to other
routers, connect the PC and the router through PSTN network.
Pre-enable the Modem dialup of the AUX port through the console port and configure the
username and password.
2.2 Establishing the Local Configuration Environment
Through the Console Port
2.2.1 Establishing the Configuration Task
Applicable Environment
You can connect the serial port of the PC to the console port of the router using the standard
RS-232 cable.
Pre-configuration Tasks
Before configuring the router through the console port, complete the following tasks:
z
Preparing the PC/terminal (including serial port and RS-232 cable)
z
Installing terminal emulation program on the PC (such as Windows XP hyper terminal)
Data Preparation
To configure the router, you need the following data.
No. Data
1 Terminal communication parameters (including baud rate, data bit, parity, stop
bit and flow control)
