8 FTP, TFTP and XModem
Quidway NetEngine20/20E
Configuration Guide - Basic Configurations
8-20 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 05 (2010-01-30)
8.8.3 Example for Configuring the FTP Client
Networking Requirements
As shown in Figure 8-3, the Router served as the FTP client can access the FTP server, and
download system software and configuration software from the FTP server..
Figure 8-3 Configuring the FTP client
Server
172.16.104.110
GE2/0/0
172.16.105.111/24
Router
IP Network
Configuration Roadmap
Users on the FTP client log on the FTP server and download system files form the server to
the storage devices on the client side.
Data Preparation
z
IP address of the FTP server
z
The destination file name and its position in the router
Configuration Procedure
Step 1 Log in to the FTP server from the router.
<Quidway> ftp 172.16.104.110
Trying ftp 172.16.104.110
Press CTRL+K to abort
Connected to ftp 172.16.104.110
220 FTP service ready.
User(ftp 172.16.104.110:(none)):huawei
331 Password required for huawei
Password:
230 User logged in.
Step 2 Configure the transmission mode to the binary format and configure the directory of the
Flash memory on the router.
[ftp] binary
200 Type set to I.
[ftp] lcd flash:/
% Local directory now flash:
Step 3 Download the newest system software from the remote FTP server on the router.
[ftp] get ne20.bin
[ftp] quit
