5 User Management
Quidway NetEngine20/20E
Configuration Guide - Basic Configurations
5-18 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 05 (2010-01-30)
The system view is displayed.
Step 2 Run:
aaa
The AAA view is displayed.
Step 3 Run:
local-user user-name access-limit access-limit
The access restriction of the local user is configured.
----End
5.4.8 Checking the Configuration
Run the following command to check the previous configuration.
Action Command
Check the attribute of the local
user.
display local-user [ domain domain-name | user-name
user-name ]
5.5 Configuration Examples
After the following two configuration examples are completed, the current user VTY0 cannot
run commands at levels higher than two. Ensure that you can log in to the router through other
methods to delete the configuration.
This section provides the following examples:
z
Example for Logging In to the Router Through Password
z
Example for Logging In to the Router Through AAA
5.5.1 Example for Logging In to the Router Through Password
Authentication
Networking Requirements
The COM port of the PC is connected with the Console port. Set the priority of VTY0 to 2
and authenticate the passwords of users. Users need to input the password Huawei to log on
successfully.
After login, if the operations are not carried out in 30 minutes, it means that the user-interface
is disconnected from the router.
