Quidway NetEngine20/20E
Configuration Guide - Basic Configurations 2 Establishment of the Configuration Environment
Issue 05 (2010-01-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2-7
2.4.3 Initializing and Configuring the Modem on the Interface
Do as follows on the router:
z
Configure the authentication mode of login user
z
Configure the authority limitation of login user
For details, refer to the Quidway NetEngine20/20E Series Routers Configuration Guide -
Security.
2.4.4 Configuring the Connection Between Remote Terminal and
the Router
Do as follows on the terminal PC:
Step 1 Run the terminal emulation program on the PC (such as Windows XP HyperTerminal) to
enter the Connection Description window.
Step 2 Enter the connection name of the PC and the router, such as Dial.
Step 3 Click OK to enter the Connect To window.
Step 4 Enter the parameters and select options.
Step 5 Click OK to enter the Connect window.
Step 6 Click Dial.
----End
2.4.5 Logging In to the Router
Enter the user name and password in the login window.
After configuration, a command line prompt such as Quidway appears. Now enter the
configuration environment in the user view.
2.5 Configuration Examples
2.5.1 Example for Login Through the Console Port
Networking Requirements
Initialize the configuration of the router when the router is powered on for the first time.
Figure 2-1 Networking diagram of logging in through the console port
Router
PC
