Unmute Microphone
If the microphone of a site is unmuted by the chair site, the site can be heard by the other sites
in the conference.
Step 1 Click Unmute Microphone.
Step 2 Choose a site whose microphone is in state, and click the site name.
When the icon is displayed, the microphone of the conference site has been unmuted, as
shown in Figure 4-16.
Figure 4-16 Unmuting a microphone
----End
Mute Microphone
If the microphone of a site is muted by the chair site, the site cannot be heard by the other
sites in the conference.
Step 1 Click Mute Microphone.
Step 2 Choose a site whose microphone is in state.
When the icon is displayed, the microphone of the conference site has been muted, as
shown in Figure 4-17.
