UPS5000-E-(50 kVA-300 kVA)
User Manual (50 kVA Power Modules)
Copyright © Huawei Technologies Co., Ltd.
X and Y are variables and stand for time.
RCCMD Certificate Management
After replacing the certificate on the MDU WebUI, replace the certificate on the RCCMD
client too. Otherwise, communication will fail. For details about the replacing method, see
the RCCMD user manual.
The default certificate provided by the system has expired. Replace the certificate
immediately.
After SSL Encrypted Transmission is set to Enable, RCCMD Certificate Management is
displayed. The RCCMD certificate, RCCMD certificate key, and RCCMD CA certificate can
be uploaded, as shown in Figure 4-70. If the RCCMD certificate or RCCMD CA certificate is
not uploaded, the default certificate provided by the system is used for communication. After
the certificate is uploaded successfully, click Submit. The WebUI of the MDU will restart,
and the uploaded certificate will be used for communication.
Figure 4-70 RCCMD certificate management
If the RCCMD certificate key has been encrypted, enable and enter the key password.
4.3.4.4 Managing the UPS by Using the NMS Complying with RFC1628
Standard
Installing the UPS MIB
The MIB is in the MDU. Click Download UPS-RFC1628-MIB on the page of the web
browser to download the MIB file which allows the third-party NMS to manage the UPS
remotely.
