UPS5000-E-(50 kVA-300 kVA)
User Manual (50 kVA Power Modules)
2 Overview
Copyright © Huawei Technologies Co., Ltd.
23
2.3 Product Introduction
2.3.1 Structure
Figure 2-8 UPS5000-E-200K-SM front view
(1) Power
modules
(2) Bypass
module
(3) Control module
(4) Power distribution
subrack cover
(5) Filler
panels
(6) Monitor
display unit
(7) Maintenance bypass
switch
(8) Folder
