3 Installation
3.1 Installation Preparations
3.1.1 Site
3.1.1.1 Dimensions
Ensure that the floor or installation support can bear the weight of the UPS5000, batteries, and
battery racks. The weight of batteries and battery racks depends on the UPS configuration for
the site.
Figure 3-1 UPS dimensions (unit: mm)
